‎Chapter 3 Display Operations Status Display
Series PM175 Powermeters 39
Total and Phase Energies
12 Ac.En.
IP.L3.
MWh
Phase L3 Wh import
13 rE.En.
IP.L3.
Mvarh
Phase L3 varh import
14 AP.En.
L3.
MVAh
Phase L3 VAh
TOU Energy Register 1
1 rEG.1
trF.1
MWh
Tariff 1 reading
2 rEG.1
trF.2
MWh
Tariff 1 reading
8 rEG.1
trF.8
MWh
Tariff 8 reading
TOU Energy Register 8
1 rEG.8
trF.1
MWh
Tariff 1 reading
2 rEG.8
trF.2
MWh
Tariff 1 reading
8 rEG.8
trF.8
MWh
Tariff 8 reading
Status Display
The meter has separate status information pages accessible
through the primary device menu. The Status Display shows
rarely used information that is especially helpful when
connecting the meter inputs and outputs to external
equipment. For information on navigating in the menus, see
Using the Menus .
To enter the Status Display:
1. From the Data Display, press the SELECT button to enter
the primary device menu. The “StA” window is highlighted.
2. Press ENTER to enter the Status Display. Use the UP
and DOWN arrow buttons to scroll through the status
pages.
To exit the Status Display:
1. Press ESC to return to the primary device menu.
2. Press ESC to return to the Data display.
Status Display
1 PhS
rot
POS/nEG/Err
Phase rotation order
2
AG.
V1 angle
V2 angle
V3 angle
Voltage angles (±180°, referenced to
V1)
3
AG.
I1 angle
I2 angle
I3 angle
Current angles (±180°, referenced to
V1)




ENERGY
ENTER
ENERGY
ENTER
ENERGY
ENTER
StA
CHG
OPS
SELECT
ENERGY
ENTER
