Appendix D Parameters for Monitoring and
Data Logging
Series PM175 Powermeters
155
Designat
ion
Description
SUM
REG2
Summary energy register #2
…
…
SUM
REG8
Summary energy register #8
PHASE
ENERGY
Phase Energy
kWh IMP
L1
kWh import L1
kWh IMP
L2
kWh import L2
kWh IMP
L3
kWh import L3
kvarh IMP
L1
kvarh import L1
kvarh IMP
L2
kvarh import L2
kvarh IMP
L3
kvarh import L3
kVAh L1
kVAh total L1
kVAh L2
kVAh total L2
kVAh L3
kVAh total L3
%HD V1
V1/V12 Harmonic Distortions
2
V1
%HD01
H01 Harmonic distortion
V1
%HD02
H02 Harmonic distortion
…
...
V1
%HD50
H50 Harmonic distortion
%HD V2
V2/V23 Harmonic Distortions
2
V2
%HD01
H01 Harmonic distortion
V2
%HD02
H02 Harmonic distortion
…
...
V2
%HD50
H50 Harmonic distortion
%HD V3
V3/V31 Harmonic Distortions
2
V3
%HD01
H01 Harmonic distortion
V3
%HD02
H02 Harmonic distortion
…
...
V3
%HD50
H50 Harmonic distortion
%HD I1
I1 Harmonic Distortions
I1
%HD01
H01 Harmonic distortion
I1
%HD02
H02 Harmonic distortion
…
...
I1
%HD50
H50 Harmonic distortion
%HD I2
I2 Harmonic Distortions
I2
%HD01
H01 Harmonic distortion
I2
%HD02
H02 Harmonic distortion
…
...
I2
%HD50
H50 Harmonic distortion
%HD I3
I3 Harmonic Distortions
I3
%HD01
H01 Harmonic distortion
