‎Chapter 3 Display Operations Data Display
38 Series PM175 Powermeters
Individual Current Harmonics
39
40H
I1 HD%
I2 HD%
I3 HD%
Order 40 harmonic distortion
Flicker/Unbalance
1
Pst
V1 Pst
V2 Pst
V3 Pst
Short term flicker
2
Plt
V1 Plt
V2 Plt
V3 Plt
Long term flicker
3 U.Unb
V% unb
Voltage negative sequence unbalance,
percent
4 C.Unb
I% unb Current negative sequence unbalance,
percent
Energy Display
Press the ENERGY button. The MVAh, Mvarh, or MWh LED is
illuminated. If TOU registers are configured in the meter, press
the button again to scroll through all active TOU registers. Use
the UP and DOWN arrow buttons to scroll through energy pages.
Along with total energies, per phase energy accumulators are
displayed if phase energy calculation is enabled in the Device
Options menu.
Total and Phase Energies
1 Ac.En.
IP.
MWh
Total Wh import
2 rE.En.
IP.
Mvarh
Total varh import
3 AP.En.
MVAh
Total VAh
4 Ac.En.
EP.
MWh
Total Wh export
5 rE.En.
EP.
Mvarh
Total varh export
6 Ac.En.
IP.L1.
MWh
Phase L1 Wh import
7
rE.En.
IP.L1.
Mvarh
Phase L1 varh import
8 AP.En.
L1.
MVAh
Phase L1 VAh
9 Ac.En.
IP.L2.
MWh
Phase L2 Wh import
10 rE.En.
IP.L2.
Mvarh
Phase L2 varh import
11 AP.En.
L2.
MVAh
Phase L2 VAh


ENERGY
ENTER


PQ
ESC
