‎Chapter 3 Display Operations Menu Operations
48 Series PM175 Powermeters
6. You are returned to the upper window to select another
counter or exit the menu.
To exit the menu, press ESC.
The following table lists available counter options.
Parameter Options Default Description
Pulse source None = disabled
Inp.1 = DI1
Inp.2 = DI2 None Links a digital input to the counter
Multiplier 1-9999 1 The value added to the counter
when a pulse is detected on the
pulse source input, or the counter is
incremented through a setpoint
action
Control Setpoint Setup
The PM175 provides 16 control setpoints with programmable
operate and release delays. Each setpoint evaluates a logical
expression with up to four arguments using OR/AND logic.
Whenever an expression is evaluated as “true”, the setpoint
performs up to four concurrent actions that can send a
command to the output relays, increment or decrement a
counter, or trigger a recorder. For more information on
setpoints operation, see
Using Control Setpoints in Chapter 4.
This menu configures setpoints through the front display. To
enter the menu, select the “SEtP” entry from the main menu,
and press the ENTER button.
The menu uses three entries:
1. The upper window indicates a setpoint number.
2. The middle window selects a setup parameter to view or
change.
3. The lower window displays the parameter value.
Use the UP and DOWN arrow buttons to scroll to the desired
setpoint.
To select a setpoint parameter:
1. Press the SELECT button to activate the middle window.
2. Use the UP and DOWN arrow buttons to scroll to the
desired parameter.
To change the parameter value:
1. Press the SELECT button to activate the lower window.
2. Use the UP and DOWN arrow buttons to select the
desired value.
3. Press ENTER to confirm the new parameter setting, or
press ESC to discard changes.
4. You are returned to the middle window to select and
configure another parameter, or confirm the setpoint
settings and exit the menu.
To store your new setpoint settings after you configured all
setpoint parameters:
1. When the middle window is highlighted, press the ENTER
button.
2. You are returned to the upper window to select another
setpoint or exit the menu.
SP.1
rtHi.C1
trG.1
SP.1
200
On.1
SEtP
ESC
SP.1
180
OFF.1
SP.1
Or
LOG.2
SP.1
rtHi.C2
trG.2
SP.1
200
On.2
