‎Chapter 3 Display Operations Menu Operations
44 Series PM175 Powermeters
Label Parameter Options Default Description
ConF Wiring connection
(configuration) mode See “Basic
Meter
Setup” in
Chapter 4
4Ln3 The wiring connection of the
device
Pt PT ratio 1.0-6500.0 1.0 The phase potential
transformer’s primary to
secondary ratio
Pt.F PT Ratio multiplier Ч1, Ч10 Ч1 PT Ratio multiplication factor.
Used in extra high voltage
networks to accommodate the
PT ratio for 500 kV and higher
networks.
U.SEC Nominal secondary
voltage
10-690 V 120 V The nominal secondary line-to-
neutral (in 4LN3, 3LN3 and
3BLN3 wiring modes) or line-to-
line (in 4LL3, 3LL3, 3BLL3,
3OP2, 3OP3 and 3DIR modes)
voltage. Used as a reference
voltage for the EN50160
evaluation.
Ct CT primary current 1-20,000 A 5 A The primary rating of the phase
current transformer
d.P Power block demand
period 1, 2, 3, 5,
10, 15, 20,
30, 60 min,
E=external
sync
30 min The length of the demand
period for power demand
calculations. If the external
synchronization is selected, a
pulse front on the digital input
DI1 denotes the start of the
demand interval.
nd.P The number of blocks in
the sliding window 1-15 1 The number of blocks to be
averaged for sliding window
demands
Ad.P Ampere, volt and THD
demand period 0-1800 sec 900 sec The length of the demand
period for ampere, volt and
THD demand calculations
Freq Nominal frequency 50,60 Hz 60 Hz The nominal line frequency
LoAd Maximum demand load
current 0-20,000 A 0 The maximum demand load
current (0 = CT primary)

Always specify the wiring mode and transformer ratings prior to
setting up setpoints and analog outputs.

The maximum value for the product of the phase CT primary
current and PT ratio is 57,500,000. If the product is greater, power
readings are zeroed.
