Page 27
2.2
PW8 Header Specifications
PW8 Header Model
SWATHMASTER™
Frame and Structure
Width To Edge of Tires
Width (Transport Lights Extended)
Depth
Height (Transport Lights Extended)
Refer to Section
Weight (Not Including Completion Packages)
3006 lb (1366 kg)
Carrier
AGCO, CLAAS, Case IH, New Holland,
John Deere, Lexion
Lighting
Two Amber Transport
Manual Storage
Header Mounted Manual Storage Case
PICK-UP
Finger Bat Width
N/A
Actual Picking Width
Draper Width
Refer to Section
Quantity of Pick-Up Fingers
392
Draper Drives
Two 5.9 cu. in. (97 cc) Hydraulic Motors
AUGER
Diameter (including Flighting)
24 in. (615 mm)
Tube Diameter
16 in. (410 mm)
Quantity of Fingers
13–22
Finger Diameter
5/8 in. (16 mm) Diameter. Induction Hardened
Speed (Combine Dependent)
141–204 rpm
DRIVELINE
Type
Heavy Duty PTO Type, Fully Shielded
With Built-In Clutch.
Connections
Locking Collar
TIRES
Size
18.5 / 8.5 x 8
Pressure
35–45 psi (240–310 kPa)
NOTE:
Specifications and design are subject to change without notice or obligation to revise previously
sold units.
169489
19
Revision A
