MTS Acumen User Manual
Page 67
Hides or shows the...
Icon
Fixture limit sliders.
Specimen limit sliders.
Fixture and specimen limit values.
Offset reference. When you apply inertial compensation (Compensate for Fixturing on
the Explorer tab), a secondary offset is applied for Axial Force to offset the force caused
by gravity on the fixturing. You cannot clear this static offset, which shows up on the right
side of the Axial Force diagram on the Situational Awareness panel. If you do not apply
inertial compensation, this offset is not shown. Hover your cursor over this offset in the
situational awareness panel to see a tooltip explanation.
Range of the last peak and valley applied.
Help indicators.
Click to open the Add/Reorder Signal Views window where you can add or remove signal
views or customize the order in which the signal views are shown in the Situational
Awareness panel. The signal views appear horizontally left-to-right on the Situational
Awareness panel according to the top-to-bottom ordering specified in the Selected Signal
Views list.
MTS Acumen
™
| 67
