Page 194
Routine Maintenance Overview Checklist
Important:
There are no customer-serviceable components on the MTS Acumen frames. Maintenance consists
of keeping the frame and work area clean, general inspection, checking interlocks, and scheduled
frame calibration.
Recommended Service
Annually
Monthly
Daily
Calendar Time Using 8 Hours Running
Time Rate per Day
2000
160
8
Running Time-Hours
X
Clean work area / machine surfaces.
X
Check frame-mounted control Emergency
Stop.
X
Check remote Emergency Stop (if
present).
X
Check test area enclosure—open door
applies low velocity.
Load Frame / Crosshead
MTS
Check crosshead locks for proper
operation.
MTS
Check crosshead lift belt for wear.
MTS
Check / adjust crosshead lift belt tension.
MTS
Check / clean crosshead lift screws.
MTS
Check / clean columns.
MTS
Assure crosshead movement is smooth.
Actuator
MTS
Check that cooling system is operational.
194 | MTS Acumen
™
