Commissioning
Important codes for quick commissioning
7
l
152 EDK82EV113 DE/EN/FR 11.0
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0014
v
Operating mode 2 2 V/f characteristic control V ~ f
(linear characteristic with constant V
min
boost)
l Commissioning is possible
without identifying motor
parameters
l Advantage of identification with
C0148:
– Improved smooth running at
low speeds
– V/f rated frequency (C0015)
and slip (C0021) are calculated
and saved. They do not have to
be entered
3 V/f characteristic control V ~ f 2
(square−law characteristic with constant
V
min boost)
4 Vector control In the case of the first selection enter
the motor data and identify them
with C0148
Otherwise commissioning is not
possible
When C0014 = 5, C0019 must be set =
0 (automatic DC injection brake is
deactivated)
5 Sensorless torque control with speed
limitation
l Torque setpoint via C0412/6
l Speed limitation via setpoint 1
(NSET1−N1) if C0412/1 is assigned,
otherwise via maximum frequency
(C0011)
C0015
uSEr
V/f rated
frequency 50.00 7.50 {0.02 Hz} 960.00 l C0015 is calculated and saved
during the motor parameter
identification with C0148.
l The setting applies to all
permitted mains voltages
C0016
uSEr
V min boost а 0.00 {0.01 %} 40.00 а device−dependent
Setting applies to all permitted mains
voltages
C0034*
v
uSEr
Range of
setpoint
selection
Standard I/O
(X3/8) Observe switch position of the
function module!
0 0 Unipolar voltage 0 ... 5 V / 0 ... 10 V
Current 0 ... 20 mA
1 Current 4 ... 20 mA Reversal of rotation direction only
possible with a digital signal.
2 Bipolar voltage −10 V ... +10 V l Minimum output frequency
(C0010) not effective
l Individually adjust offset and gain
3 Current 4 ... 20 mA open−circuit monitored TRIP Sd5 if I < 4 mA
Reversal of rotation direction only
possible with a digital signal.
