Electrical installation
Wiring
Mains choke/mains filter assignment
5
l
113 EDK82EV113 DE/EN/FR 11.0
Operation at rated power on 400/500 V mains, 3/PE
8200 vector Mains choke Interference voltage category (EN 61800−3) and motor cable
length
Component Component
Type Var. Type C2 Max.
[m]
C1 Max.
[m]
E82xV302K4C 0xx EZAELN3008B372 − 20 − 1)
2xx E82ZZ55234B200 20 E82ZZ55234B200 20
E82ZZ55234B210 50 E82ZZ55234B210 50
E82xV402K4C 0xx EZAELN3010B292 − 20 − 1)
2xx E82ZZ55234B200 20 E82ZZ55234B200 20
E82ZZ55234B210 50 E82ZZ55234B210 50
E82xV552K4C 0xx EZAELN3016B182 − 20 − 1)
2xx E82ZZ55234B200 20 E82ZZ55234B200 20
E82ZZ55234B210 50 E82ZZ55234B210 50
E82xV752K4C 0xx EZAELN3016B182 − 20 − 1)
2xx E82ZZ11334B200 20 E82ZZ11334B200 20
E82ZZ11334B210 50 E82ZZ11334B210 50
E82xV113K4C 0xx EZAELN3025B122 − 20 − 1)
2xx E82ZZ11334B200 20 E82ZZ11334B200 20
E82ZZ11334B210 50 E82ZZ11334B210 50
1) The motor cable length depends on the inverter type and the switching frequency
Operation with increased rated power
,
