Extensions for automation
Modules
6
l
129
EDK82EV113 DE/EN/FR 11.0
6
Extensions for automation
Modules
The frequency inverters are equipped with two module slots on the front of the housing:
ƒ The lower slot (FIF interface) serves to connect an I/O or bus function module.
– An I/O function module (standard I/O or application I/O) expands the controller by control
terminals for analog or digital inputs/outputs.
– Via a bus function module (e.g. PROFIBUS−DP PT or CAN PT) you connect the controller to a
fieldbus.
– A bus function module with control terminals (e.g. PROFIBUS−I/O, CAN−IO PT) is a
combination of the above−mentioned function modules.
ƒ You can connect a keypad or a communication module to the upper slot (AIF interface).
– Via the keypad you parameterise the controller according to its application, read out its
status and diagnose errors.
– Via a communication module you connect the controller to a PC or to a fieldbus.
Possible combinations
,
