Mechanical installation
Mounting with thermal separation (push−through technique)
4
l
106 EDK82EV113 DE/EN/FR 11.0
Mounting with thermal separation (push−through technique)
For this mounting variant you require the controller type E82DV...
c1
c2
g
a
d
b1 b
h
e1
e
8200vec327
Dimensions [mm]
8200 vector a b b1 c1 c2 d e 1) E1 g h
E82DV302K2C
100
292 240
25 75
270 178 109.5 5 11
E82DV402K2C
E82DV552K2C
130 27.5 102.5
E82DV752K2C
E82DV302K4C
100 25 75 E82DV402K4C
E82DV552K4C
E82DV752K4C
130 27.5 102.5
E82DV113K4C
1) If the function module is attached: observe mounting clearance and cable bending radius. The terminals of
function modules in PT design protrude above the housing by 14 mm.
