Commissioning
Parameter setting with E82ZBC keypad
Vector control
7
l
138 EDK82EV113 DE/EN/FR 11.0
Vector control
The following instructions apply to controllers equipped with a standard−I/O function module and
a three−phase AC motor which has been selected according to a power−based assignment.
Switch−on sequence Comment
1. Connect keypad
2. Ensure that controller inhibit is active after mains
connection Terminal X3/28 = LOW
3. Switch on the mains
4.
5. The keypad is in "Disp" mode after approx. 2 s and indicates
the output frequency (C0050) The USEr menu is active
6. Go to the ALL menu
7. Change to the f mode to configure the basic settings for
your drive
Blinking on the display: 0050
8. Adapt the terminal configuration to the wiring (C0007)
Lenze setting: −0−, i. e.
E1: JOG1/3 fixed setpointselection
E2: JOG2/3
E3: DCB DC brake
E4: CW/CCW rotation
9. Set the minimum output frequency (C0010)
Lenze setting: 0.00 Hz
10. Set the maximum output frequency (C0011)
Lenze setting: 50.00 Hz
11. Set the acceleration time T
ir
(C0012)
Lenze setting: 5.00 s
12. Set the deceleration time T if (C0013)
Lenze setting: 5.00 s
13. Activate the operating mode "vector control" (C0014 = 4)
Lenze setting: Linear V/f characteristic control (C0014 = 2)
14. Adapt the voltage/current range for the analog setpoint
selection (C0034)
Lenze setting: −0−, (0 ... 5 V/0 ... 10 V/0 ... 20 mA) Set the DIP switch on the standard I/O to the
same range (see Mounting Instructions for
the standard I/O)
