Commissioning
Parameter setting with E82ZBC keypad
7
l
136 EDK82EV113 DE/EN/FR 11.0
Parameter setting with E82ZBC keypad
,
Read the documentation for the keypad before starting work!
After every mains switching, or after connection of the keypad during operation, the 10 codes that
have been defined in code C0517 are immediately available.
By default, the user menu contains all codes required for commissioning a standard application with
linear V/f characteristic control:
Code Designation Lenze setting
C0050 Output frequency Display: output frequency without slip compensation
C0034 Range of setpoint
selection 0 Standard I/O X3/8: 0 ... 5 V / 0 ... 10 V / 0 ... 20 mA
Application I/O
X3/1U: 0 ... 5 V / 0 ... 10 V
X3/2U: 0 ... 5 V / 0 ... 10 V
C0007 Fixed configuration digital
inputs 0 E4 E3 E2 E1
CW/CCW DCB JOG2/3 JOG1/3
Clockwise
rotation/counter−clo
ckwise rotation
DC injection
brake Selection fixed setpoints
C0010 Minimum output
frequency 0.00 Hz
C0011 Maximum output
frequency 50.00 Hz
C0012 Acceleration time main
setpoint 5.00 s
C0013 Deceleration time main
setpoint 5.00 s
C0015 V/f rated frequency 50.00 Hz
C0016 V min boost device−dependent
C0002 Parameter set
management Re−establish delivery status; transfer parameter sets by means
of the keypad; save, load, or copy own basic settings
)
Note!
Via C0002 "Parameter set transfer/establishing the delivery status", you can transfer
configurations from drive controller to drive controller by means of the keypad, or
re−establish the delivery status by loading the Lenze setting (e. g. if you’ve lost track
during parameterising).
