Mechanical installation
Mounting by means of fixing rails
4
l
105 EDK82EV113 DE/EN/FR 11.0
Dimensions [mm]
8200 vector a b b1 b2 b3 c c1 c2 d e 1) g k
E82EV302K2C
100 333
268 240
СС
СС
СС
СС
СС
СС
СС
78
50
103
50
255 140
6.5 28
E82EV402K2C 103
E82EV552K2C 2)
125
333
359 2)
62.5
128 255
280 ... 295 2)
140
162 2) E82EV752K2C 2) 128
E82EV302K4C
100 333 50
103
255 140 E82EV402K4C 103
E82EV552K4C 103
E82EV752K4C 2)
125
333
359 2)
62.5
128 255
280 ... 295 3)
140
162 3) E82EV113K4C 2) 128
1) If the function module is attached: observe mounting clearance and cable bending radius. The terminals of
function modules in PT design protrude above the housing by 14 mm.
2) lateral mounting only possible with E82ZJ006 swivel bracket (accessories)
3) with E82ZJ006 swivel bracket (accessories)
