Page 103
Technical data
Rated data
Operation with rated power (normal operation)
l
103
EDK82EV113 DE/EN/FR 11.0
Rated data
Operation with rated power (normal operation)
For data for operation at rated mains voltage and switching frequency 8 kHz, sin. data and restrictions
for other switching frequencys see system manual.
Type
Power
Rated mains voltage
Mains current [A]
Output current [A] )
Mass
[kW]
without
with
I
r
I
max
(60 s)
1)
[kg]
P
r
mains choke
E82xV302K2C
3.0
3/PE AC 230/240 V:
180 V −0 % ... 264 V +0 %
45 Hz −0 % ... 65 Hz +0 %
DC 325 V:
260 V −0 % ... 370 V +0 %
15.6
12.0
12.0
18.0
2.9
(E82CV... 2.4)
E82xV402K2C
4.0
21.3
16.0
16.5
24.8
E82xV552K2C
5.5
29.3
21.0
22.5
33.8
3.6
(E82CV... 3.0)
E82xV752K2C
2)
7.5
−
28.0
28.6
42.9
E82xV302K4C
3.0
3/PE AC 400 V:
320 V −0 % ... 440 V +0 %
45 Hz −0 % ... 65 Hz +0 %
DC 565 V:
450 V −0 % ... 620 V +0 %
9.0
7.0
7.3
11.0
2.9
(E82CV... 2.4)
E82xV402K4C
4.0
12.3
8.8
9.5
14.2
E82xV552K4C
5.5
16.8
12.0
13.0
19.5
3.6
(E82CV... 3.0)
E82xV752K4C
7.5
21.5
15.0
16.5
24.8
E82xV113K4C
2)
11
−
21.0
23.5
35.3
E82xV302K4C
3.0
3/PE AC 500 V:
400 V −0 % ... 550 V +0 %
45 Hz −0 % ... 65 Hz +0 %
DC 710 V:
565 V −0 % ... 775 V +0 %
7.2
5.6
5.8
11.0
2.9
(E82CV... 2.4)
E82xV402K4C
4.0
9.8
7.0
7.6
14.2
E82xV552K4C
5.5
13.4
9.6
10.4
19.5
3.6
(E82CV... 3.0)
E82xV752K4C
7.5
17.2
12.0
13.2
24.8
E82xV113K4C
2)
11
−
16.8
18.8
35.3
1)
Currents for periodic load change: 1 min overcurrent time with I
max
and 2 min base load time with 75 % I
r
2)
Operation only permitted with mains choke (
^
Operation with increased rated power
,
System Manual
