7 Diagnostics & troubleshooting
7.4 Monitoring
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.4 Monitoring
The controller is provided with various monitoring functions which protect the drive against
impermissible operating conditions.
If a monitoring function responds,
• an entry will be made into the logbook of the controller,
• the response (TroubleQSP, Warning, Fault, etc.) set for this monitoring function will be
triggered,
• the status of the internal device control changes according to the selected response, controller
inhibit is set, and the "DRV- ERR" LED on the front of the controller goes on:
Response Entry in the
logbook
Display in
C00168
Pulse inhibit Controller
inhibit
Acknowledgem
ent required
LED "DRV-ERR"
None OFF
Fault     
Trouble    
TroubleQSP   
WarningLocked   
Warning  
Information  OFF
System error     Mains switching
is required!
