5 Before commissioning
5.3 General notes on applications
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Comparison of the control modes "Terminals 0/2/11/16"
The following table shows which functions of the preset application "actuating drive speed" have
been preconfigured in the prevailing control mode for a control via terminals (Lenze setting printed
in bold):
Control mode "terminals"... Function of the application
"actuating drive speed"
Info
0 2 11 16
DI1
DI2
DI1
DI2
- DI1
DI2
Overriding fixed setpoints Alternatively to the speed selection via the analog
input, "fixed setpoints" (JOG values" can also be
activated via the digital terminals.
DI1 DI2 Speed selection
LOW LOW Via analog input 1
(Terminal A1U)
HIGH LOW Fixed setpoint 1
(C00039/1: 40 %)
LOW HIGH Fixed setpoint 2
(C00039/2: 60 %)
HIGH HIGH Fixed setpoint 3
(C00039/3: 80 %)
DI3 - DI2 - Manual
DC-injection braking
Manual DC-injection braking allows the drive to be
quickly braked to a standstill without the need to use
an external brake resistor.
- DI3 - - Quick stop The quick stop function decouples the motor control
from the setpoint selection. The motor is braked to
standstill with the adjustable ramp time (n
act
= 0).
DI4 DI4 DI1 - Change of direction of
rotation
- - - DI3
DI4
Fail-safe
selection of direction of
rotation
DI3 DI4 Selection of direction of
rotation
LOW LOW Quick stop
HIGH LOW Clockwise rotation
LOW HIGH Counter-clockwise rotation
HIGH HIGH No change
- - DI3
DI4
- Motor potentiometer This motor potentiometer function replaces a
hardware motor potentiometer and can be used as
an alternative setpoint source which is controlled via
two inputs.  Motor potentiometer ( 65)
DI3 DI4 Function
LOW LOW No change
HIGH LOW Increase speed
LOW HIGH Decrease speed
HIGH HIGH No change
- - - - Process controller If required, the process controller can be
implemented in the signal flow of the application via
configuration parameters.  Process controller
( 68)
