5 Before commissioning
5.2 General notes on parameters
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Menu structure
In the keypad, the parameters are classified into various menus and submenus.
• The USER menu includes a selection of frequently used parameters. ( 20)
• The Code list contains all parameters.
• The Go to param function enables you to reach the corresponding parameter directly.
• The Logbook logs all errors and their chronological history.
• The Diagnostics menu contains diagnostic/display parameters for displaying device-internal
process factors, current actual values and status messages.
LCD display
Headline
In the menu level: Menu name
In the parameter level: Parameter name
Three-part display
In the menu level: List of available menus
In the parameter level: Code/subcode and setting or actual value
Device status
 Controller is switched on  Pulse inhibit is active
 Controller is enabled  System fault is active
 Controller is inhibited  "Fault" device status is active
 Quick stop is active  Device status "Trouble" active
 Current limit exceeded  Device status "TroubleQSP" active
 Speed controller 1 in the limitation  A warning is indicated
Function - left function key Function - right function key
 Change parameter setting
(change to editing mode)
 Accept change in the controller
(no saving with mains failure protection   )
 Back to main menu  Abort (discard change)
 Parameter can only be changed when the controller is inhibited.
 Save all parameter settings in the memory module safe against mains failure
Control elements
 Execute the function assigned to the function key (see LCD display)
 Execute the stop function set in C00469 (Lenze setting: Inhibit controller)
 Deactivate stop function again (Lenze setting: Enable controller again)
 In the menu level: Select menu/submenu
In the parameter level: Select parameter
In the editing mode: Change marked digits or select list entry

 In the menu level: Select submenu/change to parameter level
In the editing mode: Cursor to the right
 In the menu level: One menu level higher (if available)
In the parameter level: Back to menu level
In the editing mode: Cursor to the left
