Figure 4-9: wing lift adjustment – Landoll 2131 Wing Coulter Chisel User Manual
Page 85
OPERATION AND MAINTENANCE
4-9
3.
An adjusting wrench is provided to make this
adjustment. It may be necessary to lower the wing to
the ground and relieve weight on the cylinder anchor
to make this adjustment. If required, fully raise the
implement, lower to just above the ground, and
re-verify measurements. Repeat as necessary and
securely tighten the cylinder anchor when complete.
Figure 4-9: Wing Lift Adjustment
2130wingliftadj
4 X 16 HYDRAULIC
CYLINDER
WHEEL LIFT
WHEEL
ASSEMBLY
BASE END
ADJUSTMENT
WING
FRAME
