2-8 F-721-0513 Edition
STANDARD SPECIFICATIONS
Figure 2-3: Auto Reset Shank and Light Bracket Placement (2131-19)
2130-19 shank-light placement
5”
5”
4-1/4”
5-1/8”
20-1/8”
5-1/8”
4-1/4”
5”
5”
4-7/8”
5-1/8” 5-1/8”
5-1/8” 5-1/8” 5-1/8”
5-1/8”
NOTE: LT AND RT INDICATES
THE RECOMMENDED PLACEMENT
FOR TWISTED SHOVELS.
5-1/8” 4-7/8”
5-1/8”
RT
LT RT RT RT RT LT LT LT
LT RT RT RT RT LT LT LT RT LT
