Assembly instructions – Landoll 2131 Wing Coulter Chisel User Manual
Page 58
3-22
F-721-0513 Edition
ASSEMBLY INSTRUCTIONS
Figure 3-14: Coulter Lift Hydraulic Installation (2131-21, 2131-23, & 2131-25)
2131 21-25 coulters op
90 ADAPTER
4 X 8 REPHASE
HYDRAULIC
CYLINDER
3/8 X 130 HOSE
ASSEMBLY
3-3/4 X 8 REPHASE
HYDRAULIC
CYLINDER
3/8 X 105 HOSE
ASSEMBLY
3-1/2 X 8 REPHASE
HYDRAULIC
CYLINDER
3/8 X 120 HOSE
ASSEMBLY
3-1/4 X 8 REPHASE
HYDRAULIC
CYLINDER
90 ADAPTER
90 ELBOW W/
RESTRICTOR
90 ADAPTER
3/4-16 MALE COUPLER
3/8 X 3
90 ADAPTER
3/8 X
HOSE
ASSEMBLY
72 HOSE
ASSEMBLY
342
MASTER
SLAVE 1
SLAVE 2
SLAVE 3
