Landoll 2131 Wing Coulter Chisel User Manual
Page 32
2-24
F-721-0513 Edition
STANDARD SPECIFICATIONS
Figure 2-19: Standard and Hydraulic Tubular Mount Chopper Reel Placement (2131-25)
NOTE:
SHANK MODEL SHOWN. CHOPPER REELS
ATTACH TO
MODELS USING SAME
DIMENSIONS.
SHANK
AUTO RESET
RIGID SHEAR
2130-25
38
53-1/4
3-1/2
3-1/2
37
56
2130-25 chopper reel placement
129” REEL
ASSEMBLY
129” REEL
ASSEMBLY
129” REEL
ASSEMBLY
28
53-1/4
37
28
3-1/2
