Landoll 2131 Wing Coulter Chisel - Manual (Page 17)

STANDARD SPECIFICATIONS
2-9
Figure 2-4: Rigid Shear Shank and Light Bracket Placement (2131-19)
2130-19_rsb shank-light placement
5”
5”
4-1/4”
5-1/8”
20-1/8”
5-1/8”
4-1/4”
5”
5”
4-7/8”
5-1/8” 5-1/8” 5-1/8” 5-1/8” 5-1/8” 5-1/8”
NOTE: LT AND RT INDICATES
THE RECOMMENDED PLACEMENT
FOR TWISTED SHOVELS.
5-1/8”
4-7/8”
5-1/8”
RT
LT
RT
RT
RT
RT
LT
LT
LT
LT RT
RT
RT
RT LT
LT
LT
RT
LT
