ASSEMBLY INSTRUCTIONS
3-25
Figure 3-17: Fold Hydraulic Installation (2131-17 & 2131-19)
2131 17-19 fold hyd
(G)
(A)
(B)
(C)
(H)
(D)
(C)
(D)
(O)
(P)
90 ELBOW W/
RESTRICTOR
70
90 ADAPTER
3/8 X 120 HOSE
ASSEMBLY
90 ADAPTER
90 ADAPTER
3/8 X 24 HOSE
ASSEMBLY
90 ELBOW W/
RESTRICTOR
3/8 X HOSE
ASSEMBLY
5/16 X 2-1/2 SPRING
SLOTTED PIN
1-1/4N FLAT
WASHER
FOLD PIN
4 X 30
HYDRAULIC
CYLINDER
3/8 X 36 HOSE
ASSEMBLY
1/2-13 X 3-1/2
HEX HEAD CAP
AND HEX LOCK
NUT
8 PORT
MANIFOLD
3/8 X 24 HOSE
ASSEMBLY
4 X 30
HYDRAULIC
CYLINDER
FOLD PIN
1-1/4N FLAT
WASHER
5/16 X 2-1/2
SPRING
SLOTTED PIN
3/8 X 214 HOSE
ASSEMBLY
3/4-16 MALE
COUPLER
16 PORT MANIFOLD
(A)
(B)
(C)
(D)
(I)
(J)
(K)
(L)
(M)
(N)
(O)
(P)
(E)
(F)
(G)
(H)
FRONT OF MACHINE
PLUG PORTS B,G,H,K,L,&M
(A)
(B) (G)
(H) (E)
(F) (C)
(D)
FRONT OF MACHINE
PLUG PORTS E & F
