Page 57
ASSEMBLY INSTRUCTIONS
3-21
Figure 3-13: Coulter Lift Hydraulic Installation (2131-17 & 2131-19)
2131-17 19 coulters op
90 ADAPTER
4 X 8 REPHASE
HYDRAULIC
CYLINDER
3/8 X 105 HOSE
ASSEMBLY
3-3/4 X 8 REPHASE
HYDRAULIC
CYLINDER
3/8 X 105 HOSE
ASSEMBLY
3-1/2 X 8 REPHASE
HYDRAULIC
CYLINDER
3/8 X 96 HOSE
ASSEMBLY
3-1/4 X 8 REPHASE
HYDRAULIC
CYLINDER
90 ADAPTER
90 ELBOW W/
RESTRICTOR
90 ADAPTER
3/4-16 MALE COUPLER
3/8 X 342
90 ADAPTER
3/8 X 312 HOSE
ASSEMBLY
HOSE
ASSEMBLY
MASTER
SLAVE 1
SLAVE 2
SLAVE 3
