Landoll 2131 Wing Coulter Chisel - Manual (Page 42)

3-6 F-721-0513 Edition
ASSEMBLY INSTRUCTIONS
Depth Stop Tube Assembly
1. Attach the depth stop mount plate to the shank lift
using 3/8-16 x 1-1/4 hex head cap screws and hex
lock nuts.
2. Lay the depth stop tube assembly on top of the
center frame. Insert a 5/8-11 x 2-1/2 hex head cap
screw in the rear hole of the tube assembly from the
left side (See Figure 3-3.) Install a 5/8-11 hex lock
nut on the screw. Do not over tighten, as the depth
stop must pivot on this screw.
3. Insert 90
o
elbow fittings in the back of the limit valve
and a straight adapter in the side nearest the center
of the machine.
4. Using 5/16-18 x 5 hex head cap screws secure the
front end of the depth stop tube assembly to the top
of the frame mount with the depth stop guide, slide
pad, and 5/16-18 hex lock nuts. Attach the limit valve
to the bottom side of the center frame mount using
these same screws.
IMPORTANT
It may be necessary to leave these screws loose to
attach the valve hoses later.
