Figure 3-31: coil tine harrow installation – Landoll 2131 Wing Coulter Chisel User Manual
Page 73
ASSEMBLY INSTRUCTIONS
3-37
Figure 3-31: Coil Tine Harrow Installation
3/4-10 X 3 HEX HEAD
CAP SCREW
2 HOLE SUPPORT
PLATE (INSIDE TUBE)
COIL TINE HARROW
ARM ASSEMBLY
3/4-10 HEX LOCK NUT
5/8-11 FLANGE HEAD
SERRATED NUT
HARROW STIFFENER
PLATE
3 ROW HARROW
ASSEMBLY
3/4-10 X 13 HEX HEAD
CAP SCREW
MOUNT PLATE
ARM SUPPORT TUBE
MOUNT PLATE
3/4-10 HEX LOCK NUT
U-BOLT
2130-21-tine-1
