Landoll HSB 71-1 through 131-1 SOIL BUILDER Coulter Chisel - Extended Frame User Manual
Page 33
1K705
Figure 11
Note: Refer to this Illustration for assembly of “11-Shank” & “13-Shank” models
with Walking Beam Axles. R and L above refer to location of right and left
hand shank assemblies
Use 9.5L - 15
or
11L-15 6-8 Ply Tires
Front
(2) 7J656
13-shank
only
(2) 7J655
13-shank
only
C
L
15
15
15
15
15
15
15
15
15
15
15
15
11 & 13-Shank Tandem Wheel
Page 31
791rev5-30-05
R
L
R
R
R
R
R
L
L
L
L
L
R
