Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 9)

ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GD1113
G10230
G10104 2
4
4 U-Bolt, 5” x 7” x ⅝”-11
Lock Washer, ⅝”
Hex Nut, ⅝”-11
2 GD10036 1 Mounting Support Plate
3 GB0218 8 Bushing, 21/32” I.D. x ⅞” O.D. x 19/32” Long
4 GD11422 2 Upper Parallel Arm
5 G11391 8 Flat Washer, ⅝” SAE
6 G10732
G10412 4
4 Hex Head Cap Screw, ⅝”-18 x 2”
Lock Nut, ⅝”-18
7 GB0186 2 Spring Anchor
8 GD14217 2 Tab Lock Pin, 7/16” x 1½”
9 GD8249
GD21337 4
-
Standard Down Pressure Spring
Heavy Duty Down Pressure Spring
10 G10752
G10412 2
2 Hex Head Cap Screw, ⅝”-18 x 2¼”
Lock Nut, ⅝”-18
11 GA5651 1 Lower Parallel Arm
12 G10751
G10412 2
2 Hex Head Cap Screw, ⅝”-18 x 1¾”
Lock Nut, ⅝”-18
13 GA1720 1 Bearing/Sprocket, ⅞” Hex Bore
14 G10004
G11091 2
2 Hex Head Cap Screw, ⅜”-16 x 1¼”
Serrated Flange Nut, ⅜”-16
15 G10007
G10230
G10104 4
4
4 Hex Head Cap Screw, ⅝”-11 x 1½”
Lock Washer, ⅝”
Hex Nut, ⅝”-11
16 GB0366 2 Extension Bracket
17 GA18724 - Row Unit Mount (Optional on 4 Center Row Units When Using Frame Mounted
Coulters with Residue Wheels Along with GB0366 Extension Bracket)
A G6325X - U-Bolt Package For 5" x 7" Toolbar, Includes: (2) GD1113, (4) G10230, (4) G10104
Parallel Arms, Mounting Support Plate, and Quick Adjustable
Down Force Springs Option
Model 3500 M0240-02
Rev. 5/14 P6
