Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 85)

Seed Rate Transmission Assembly
ITEM PART NO. QTY. DESCRIPTION
35 GA5106
GA5108
GA5202 1
-
-
Sprocket, 17 Tooth, Standard Drive (Mechanical)
Sprocket, 23 Tooth, (EdgeVac)
Sprocket, 34 Tooth, Half Rate (2 To 1) Drive Reduction (Mechanical only)
36 G10460 1 Cotter Pin, ¼" x 2"
37 GA7841 1 Bearing, ⅞" Hex Bore, Spherical
38 G3400-01 2 Flangette
39 GD5830 1 Angle Support, R.H.
40 GD5824 1 Plate, R.H.
41 GD9047 1 Spacer
42 G10053
G10228
G10102 1
1
1 Hex Head Cap Screw, ½"-13 x 2½"
Lock Washer, ½"
Hex Nut, ½"-13
43 GD12571 1 Spacer, 1" x 4"
44 G11100
G10227
G11453 1
1
1 Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Fender Washer, ¼"
45 G11078 1 Vinyl Cap
46 G10038
G10128
G10228
G10102 1
-
1
1
Hex Head Cap Screw, ½"-13 x 3"
Machine Bushing, ½", 14 Gauge (As Required)
Lock Washer, ½"
Hex Nut, ½"-13
47 GB0259 - Spacer, 1"
48 GA7841 - Bearing, ⅞" Hex Bore
49 GD16302 - Reverser Plate
50 G10017
G10228
G10102 2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
51 GA12178 1 Sprocket Storage Rod (EdgeVac) See Item No. 21 for Sprockets
52 GD2558 - Lynch Pin, ¼"
A G1K378 1 Wrap Spring Wrench Replacement Kit, Gold Collar, R.H. (Items 1, 4, 15, 16, 23, 24,
27, 44 And 45)
