Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 7)

ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GD1113
G10230
G10104 2
4
4 U-Bolt, 5" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
2 GD10036 1 Mounting Support Plate
3 GB0218 4 Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
4 GD11422 2 Upper Parallel Arm
5 G10732
G11391
G11514 4
4
4 Hex Head Cap Screw, ⅝"-18 x 2"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-18
6 GA5651 1 Lower Parallel Arm
7 GA1720 1 Bearing/Sprocket, ⅞" Hex Bore
8 G10004
G11091 2
2 Hex Head Cap Screw, ⅜"-16 x 1"
Serrated Flange Nut
9 --- - See “Hopper Support and Meter Drive” on page P17
10 GA11982 1 Air Spring Assembly
11 GD23995 1 Saddle
12 G11018
G11391
GD3180-30 2
2
2 Hex Head Cap Screw, ⅝"-18 x 1¼"
Flat Washer, ⅝" SAE
Sleeve, ⅞" O.D. x ⅝" I.D. x 21∕32"
13 GB0396 1 Head Mount
14 GB0397 1 Shoulder Nut, ¾"-16
15 GB0395 2 Bracket
16 G11220
G10071 4
4 Hex Socket Cap Screw, ½"-13 x 1½"
Serrated Flange Nut, ½"-13
17 G10004
G11387
GD11963-04
G10108 2
2
2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Spacer, ¼"
Lock Nut, ⅜"-16
18 GD17794 1 Link (not applicable with row unit extension brackets)
19 GB0393 1 Plate
20 G10037
G11389
G10228 7
2
7 Hex Head Cap Screw, ½"-13 x 1¼"
Flat Washer, ½" SAE (Lower Two Holes Only)
Lock Washer, ½"
21 --- - See “Interplant Push Row Unit” on page P43
22 GB0390 1 Yoke Mount
23 GB0392 1 Yoke
24 GB0391 1 Mount
25 G10017
G11389
G10228
G10102 2
2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
26 GB0389 1 Plate
27 G10007
G10230
G10104 4
4
4 Hex Head Cap Screw, ⅝"-11 x 1½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
28 GB0366 2 Extension Bracket
29 GB0398 1 Extension
30 G10039
G11389
G10111 4
4
4 Hex Head Cap Screw, ½"-13 x 1¾"
Flat Washer, ½" SAE
Lock Nut, ½"-13
31 G10037
G10228 1
1 Hex Head Cap Screw, ½"-13 x 1¼"
Lock Washer, ½"
A G6325X - U-Bolt Package For 5" x 7" Toolbar, Includes: (2) GD1113, (4) G10230, (4) G10104
Parallel Arms, Mounting Support Plate, and Pneumatic Down
Pressure Package Option
Model 3500 M0240-02
Rev. 5/13 P4
TM
