Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 89)

ITEM PART NO. QTY. DESCRIPTION
1 GD18112
G11066
G10992 1
4
4 Cover
Phillips Pan Head Machine Screw, No. 10-24 x ¾", Stainless Steel
Serrated Flange Nut, No. 10-24
2 GA14127
GR1943 1
1 Filter Assembly
Filter
3 GA12102
G11066
G10992 1
4
4 Air Compressor
Phillips Pan Head Machine Screw, No. 10-24 x ¾", Stainless Steel
Serrated Flange Nut, No. 10-24
4 GA12358
G10019
G10232
G11386
G10106 1
4
4
4
4 Mount
Hex Head Cap Screw, 5/16"-18 x 1"
Lock Washer, 5/16"
Flat Washer, 5/16" SAE
Hex Nut, 5/16"-18
5 GD11721
G10228
G10102 2
4
4 U-Bolt, 5" x 7" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
6 GD18119 2 Compressor Mount
7 G10106
G10232
G11386
G10019 4
4
4
4 Hex Nut, 5/16"-18
Lock Washer, 5/16"
Flat Washer, 5/16" SAE
Hex Head Cap Screw, 5/16"-18 x 1"
8 GA11988 1 Tank, 3 Gallon
9 GA13512 1 Valve Stem, ¼" NPT
10 GD19237 2 Tee, ¼" NPT
11 GD17156 3 Plug, ¼" NPT
12 GD19238 2 Nipple, ¼" NPT
13 GR1778 1 Pressure Switch
14 GA11991 1 Drain, ¼" NPT
15 GR1951 1 Leader Hose without Check Valve
16 GR1921 1 Check Valve
17 GA12104 1 Pressure Gauge, ¼" NPT
18 GD17141 2 Connector, ¼" Male
19 GD18078 1 Female Cross, ¼" NPT
20 GD17154 1 Connector, ¼" Male
21 GA11994
G11311 2
4 Solenoid
Slotted Pan Head Machine Screw, M4-.07 x 8mm
22 GD17156 2 Plug, ¼" NPT
23 GA11993 1 Block
24 GD17143 1 Swivel Elbow, ¼" NPT x ⅜"
25 G10040
G10227 2
2 Hex Head Cap Screw, ¼"-20 x 1¾"
Lock Washer, ¼"
26 GA11997 1 Breather, ¼" NPT
27 GR1952
GR1953
G10256 4
4
4 Socket Head Cap Screw, #8-32 x 2"
O-Ring
Lock Washer, No. 8
28 GA11992 1 Shutoff Valve, ¼" NPT
29 GA13169
GR1843 1
-
Tube Cutter W/Blade
Blade
30 --- - See “Parallel Arms, Mounting Support Plate, and Pneumatic Down Pressure
Package Option” on page P3
31 GD18274 - Tee, ⅜" x ⅛" NPT Extended, Push Row Unit
32 GD17150-01
GD17150-02
GD17150-11
GD17150-10
GD17150-12 -
-
-
-
- Nylon Tubing, ⅜" O.D. x 32', 6 Row Pull Row Units
Nylon Tubing, ⅜" O.D. x 44', 8 Row Pull Row Units
Nylon Tubing, ⅜" O.D. x 28', 5 Row Push Row Units
Nylon Tubing, ⅜" O.D. x 40', 7 Row Push Row Units
Nylon Tubing, ⅜" O.D. x 5', Even-Row Push Row Unit
33 GD18010 - Tee, ⅜" Tube Union
34 GD18011 - Elbow, ⅜" x ⅛" NPT Extended
A GA12626 1 Air Compresor Assembly (Items 1-4, 8-14)
B GA11995 1 Dual Solenoid Assembly (Items 17-19, 21-24, and 26-28)
C GR1783 - Valve Seal Kit
Pneumatic Down Pressure Air Compressor, Dual Solenoid
Assembly, Tubing, and Fittings
Model 3500 M0240-02
6/11 P86
TM
