P102 – Kinze 3500 Lift and Rotate Planter Rev. 5/14 User Manual
Page 105
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA6699
GA6700
GR1956
GR1957
GR1958
GR1208
1
1
-
-
-
-
Double Light Assembly
Double Light Assembly (Shown)
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Red Lens Kit, Includes: (1) Red Lens, (1) Gasket, and (3) Hex Head Cap Screws
Black Cover Kit, Includes: (1) Black Cover, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
2
GA9152
GA9153
GA5385
-
-
-
Wiring Harness W/7 Terminal Female Connector, 516" (2 Light Connections), 6 Row 30"
Wiring Harness W/7 Terminal Female Connector, 564" (2 Light Connections), 8 Row 30"
7 Terminal Female Connector
3
GA9096
2
Harness Extension, 42"
4
G1K248
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
5
G1K252
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
6
GD11089
-
Sealing Plug
7
GA8047
-
Dust Plug (Black)
8
GD6291
GD22965
G11091
1-2
-
-
Insulated Clamp, ⅜"
Insulated Clamp, ¼"
Serrated Flange Nut, ⅜"-16
9
GA15101
GR1981
2
-
Work Light Assembly
Bulb H3-55W
10
GA10924
1
Wiring Harness, 348"
11
G1K321
-
2-Pin Female Connector Kit (Black), Includes: (3) 2-Pin Female Housings, (6) Pin
Contacts, (6) Seals
12
G1K320
-
2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
13
G10001
G10229
G10101
2
2
2
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
14
GD12703
1
Push Row Unit Light Bracket
Electrical Components
Model 3500
M0240-02
6/11
P102
TM
