Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 147)

Liquid Fertilizer Piston Squeeze Pump Mounting Brackets and
Driveline
ITEM PART NO. QTY. DESCRIPTION
13 GD11045 5 Lock Clamp
14 G10130
G10923 5
5 Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
15 --- - See “Liquid Fertilizer Tanks, Saddles, Mounts, Hoses, and Fittings” on page P131
16 GA4619 1 Pump Mount, L.H.
17 GA7336
GD7426
GD1026
G11387
G10229
G10047 1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Head Cap Screw, ⅜"-16 x 1¾"
18 GA4620 1 Pump Mount, R.H.
19 GD2548-30 1 Hex Shaft, ⅞" x 30" (1 Hole)
20 G10004
G11387
G10229
G10101 4
4
4
4 Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
21 GD6165 - Plate (8 Row 30" Only)
22 GD5857 1 Spring
23 GA6403
G10641
G10640 1
-
-
Drive Plate W/Grease Fitting
Grease Fitting, ⅛" NPT
Grease Fitting, ¼"-28
24 GD1134
G10230
G10104 1
2
2 U-Bolt, 7" x 5" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
25 GD1113
G10230
G10104 2
4
4 U-Bolt, 5" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
26 G3310-154
GR0912 1
-
Chain, No. 40, 154 Pitch Including Connector Link
Connector Link, No. 40
27 G2100-03 2 Bearing, ⅞" Hex Bore, Spherical
28 G3400-01 4 Flangette
29 G10303
G10232
G10106 6
6
6 Carriage Bolt, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
30 GD1719
G10409 1
1 Coupler, 4"
Retaining Ring, 5∕16"
31 GD19343
GD19344 1
-
Release Collar, R.H. (Shown)
Release Collar, L.H.
32 GD14427 1 Tightener Shaft, 4⅞"
33 GD14431 1 Handle
34 GD2734-08 1 Sleeve, 1¼" O.D. x ⅝" Long
35 G11100
G10227
G11453 1
1
1 Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Fender Washer, ¼"
36 G11078 1 Vinyl Cap
37 G10496 2 External Inverted Snap Ring, 1½"
38 G11075 2 External Inverted Snap Ring, ⅞"
39 GD14432 1 Sleeve, 1 ¼"
40 GD14413
GD14414 -
1
Torsion Spring, L.H. (Used In R.H. Wrap Spring Wrench)(Shown)
Torsion Spring, R.H. (Used In L.H. Wrap Spring Wrench)
A G1K269 - Lock Clamp Kit (Items 13 And 14)
B G1K379 - Wrap Spring Wrench Replacement Kit, Silver Collar, L.H. (Items 31-40)
Model 3500 M0240-02
6/11 P144
