Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 137)

Liquid Fertilizer Piston Pump Mounting Brackets and Driveline
ITEM PART NO. QTY. DESCRIPTION
12 --- - See “Liquid Fertilizer Tanks, Saddles, Mounts, Hoses, and Fittings” on page P131
13 G10626 4 Adapter, 1¼" NPT To Barb
14 GA3893
GR0880
GR0881
GR0882
GR0883 1
-
-
-
-
Strainer Complete
Screen, No. 40 Mesh
Gasket
Y-Body
End Cap
15 G10053
G10228
G10501
G10102 1
1
1
1 Hex Head Cap Screw, ½"-13 x 2½"
Lock Washer, ½"
Hex Jam Nut, ½"-13, Grade 2
Hex Nut, ½"-13
16 GD5857 1 Spring
17 G10036
G10230
G10503
G10104 1
1
1
1 Hex Head Cap Screw, ⅝"-11 x 4"
Lock Washer, ⅝"
Hex Jam Nut, ⅝"-11, Grade 2
Hex Nut, ⅝"-11
18
GA11024
GA7154
G10038
G10168
GD11158
G10501 1
1
1
4
1
1 Idler W/Sprocket And Hardware
Sprocket W/Bearing, 18 Tooth
Hex Head Cap Screw, ½"-13 x 3"
Machine Bushing, ½", 7 Gauge
Spacer, ¾" O.D. x 9∕16" Long
Hex Jam Nut, ½"-13, Grade 2
19 G10017
G10228
G10102 1
1
1 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
20 GD1113
G10230
G10104 2
4
4 U-Bolt, 5" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
21 GD16157 1 Bracket
22 GA10603 1 Pump Mount, L.H.
23 GA4620 1 Pump Mount, R.H.
24 G10003
GR1122
G11387
G10229
G10101 4
4
4
4
4 Hex Head Cap Screw, ⅜"-16 x 1½"
Mounting Pad
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
25 G10478
G10409 1
1 Clevis Pin, 5∕16" x 1"
Retaining Ring, 5∕16"
26 G3310-88
GR0912 1
-
Chain, No. 40, 88 Pitch Including Connector Link
Connector Link, No. 40
27 G10670 1 Hair Pin Clip, No. 3
28 G2100-03 1 Bearing, ⅞" Hex Bore, Spherical
29 G3400-01 2 Flangette
30 G10303
G10620 3
3 Carriage Bolt, 5∕16"-18 x 1"
Serrated Flange Nut, 5∕16"-18
31 GD11045 5 Lock Clamp
32 G10130
G10923 5
5 Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
33 GD1719 1 Coupler, 4"
34 G10233 1 Machine Bushing, 1½" x 1∕32", 10 Gauge
35 GA5194 1 Sprocket, 50 Tooth
36 G10003
G10229
G10101 1
1
1 Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
37 G11237 1 Reducing Bushing, 1½" Male NPT To ¾" Female
38 --- - See “Liquid Fertilizer Piston Pump Uses 18 Tooth Sprocket” on page P139
Model 3500 M0240-02
Rev. 5/14 P134
