Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 71)

ITEM PART NO. QTY. DESCRIPTION
1 GA13665 1 Hitch Pivot (March 1, 2009 and on)
2 GA13783 1 Pivot Mount
3 G10169
G10157 2
2 Hex Head Cap Screw, 1¼"-7 x 6"
Lock Nut, 1¼"-7
4 GA12163
GD15725 1
1 Pin, 13⅜"
Washer, 4" O.D. x 2¼" I.D. x ¼"
5 GD17245
G11223
G10118 1
1
1 Washer, 4" O.D. x 11∕32" I.D. X ⅜"
Hex Head Cap Screw, 1"-8 x 2"
Lock Washer, 1"
6 GD15100
G10230
G10217
G10005 1
1
1
1 Pivot Lock
Lock Washer, ⅝"
Washer, ⅝" USS
Hex Head Cap Screw, ⅞"-11 x 1¾"
7 GD16226
GD16303 1
2 Sleeve, 3" O.D. x 125∕32" x 29∕32" Thick
Washer, 3" O.D. x 125∕32" x ¼" Thick
8 GA13673 1 Pivot Pin (March 1, 2009 and on)
9 GA11079
G10007
G10230 2
2
2 Hammer Strap, Category 3 And 3N
Hex Head Cap Screw, ⅝"-11 x 1½"
Lock Washer, ⅝"
10 GA12164 1 Hitch Bar
11 GD19468 1 Tapped Bar
12 GA11082
G10640
GD16303
GD16226 1
-
2
1
Pivot Bolt W/Grease Fitting, 1¾" x 10⅜" (Total Length) (Prior to March 1, 2009)
Grease Fitting, ¼"-28
Washer, 3" O.D. x 125∕32" x ¼" Thick
Sleeve, 3" O.D. x 125∕32" x 29∕32" Thick
13 GA11083
GD14562
G10779 1
2
2 Hitch Pivot W/Bushings And Grease Fittings (Prior to March 1, 2009)
Hardened Bushing, 2¾" O.D. x 2¼" I.D. x 3"
Grease Fitting, 90°, ¼"-28
2-Point Hitch Option
Model 3500 M0240-02
6/11 P68
