Outer Hitch
ITEM
PART NO.
QTY.
DESCRIPTION
5
GD4743
GA7022
G10071
3
1
6
U-Bolt, 3" x 3" x ½"-13
Detent Pin W/Chain
Serrated Flange Nut, ½"-13
6
GA6623
GA6418
-
-
Transport Post, 6 Row 30"
Transport Post, 8 Row 30" (Shown)
7
G10104
G10230
G10005
G11391
4
4
4
8
Hex Nut, ⅝"-11
Lock Washer, ⅝"
Hex Head Cap Screw, ⅝"-11 x 1¾"
Flat Washer, ⅝" SAE
8
GA9559
1
See “Transport Latch Cylinder, All Sizes” on page P93
9
GD7137
G10457
1
2
Pin, ¾" x 3⅜"
Cotter Pin, 5∕32" x 1½"
10
G10809
GD2971-09
GD3180-03
G10108
1
1
-
2
Hex Head Cap Screw, ⅜"-16 x 3¼"
Sleeve, 2" Long
Sleeve,
⅝
" I.D. x
⅞
" O.D. x 115∕16" Long (As Required)
Lock Nut, ⅜"-16
11
G6801-06-08
GR1037
2
-
Elbow W/O-Ring, 90°, 9∕16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
12
GA6438
-
See “Selector Valve” on page P96
13
G10746
G10110
2
2
Hex Head Cap Screw, ¼"-20 x 2¾"
Lock Nut, ¼"-20, Grade B
14
G10716
GD2169
G10231
2
2
2
Hex Head Cap Screw, ¾"-10 x 1"
Special Washer, 25∕32" I.D. x 1¼" O.D., Hardened
Lock Washer, ¾"
15
G10717
G10239
G10236
1
1
1
Hex Head Cap Screw, 1¼"-7 x 9"
Hex Nut, 1¼"-7
Lock Washer, 1¼"
16
GA6404
G10104
G10230
G10005
G11391
1
4
4
4
8
Jack Storage Mount
Hex Nut, ⅝"-11
Lock Washer, ⅝"
Hex Head Cap Screw, ⅝"-11 x 1¾"
Flat Washer, ⅝" SAE
17
GD0740
G10111
2
1
Hose Clamp, ¾" x 4" x 3½"
Lock Nut, ½"-13
18
GD5875
G10108
2
2
Hose Clamp, 9∕16" x 2½" x 2"
Lock Nut, ⅜"-16
19
GA11201
1
Hose Support
20
G10102
G10228
GA6608
1
1
1
Hex Nut, ½"-13
Lock Washer, ½"
Cable Assembly
21
GD9046
G10004
1
1
Hose Clamp, 3 ¼" x 4"
Hex Head Cap Screw, ⅜"-16 x 1¼"
22
G10048
GD16341
G10229
1
1
1
Hex Head Cap Screw, ⅜"-16 x 2"
Hose Clamp, 3¾" x 6"
Lock Washer, ⅜"
23
G10004
G10108
4
4
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Nut, ⅜"-16
24
GA6371
1
Outer Hitch, 125½"
25
GD9129-01
1
Hose Protector, 48"
26
GD14106
1
Channel (If Applicable)
27
GD10731
1
Wire Clamp (If Applicable)
28
G10004
G10108
2
2
Hex Head Cap Screw, ⅜"-16 x 1¼" (If Applicable)
Lock Nut, ⅜"-16 (If Applicable)
29
GA11528
-
Bracket
30
GD16642
G10228
G10102
2
4
4
U-Bolt, 3" x 4" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
31
G10027
GD2169
G10105
8
8
8
Hex Head Cap Screw, ¾"-10 x 2½"
Special Washer, 25⁄32" I.D. x 1¼" O.D., Hardened
Hex Nut, ¾"-10
