Kinze 3500 Lift and Rotate Planter Rev. 5/14 User Manual
Page 57
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA11154
1
Digital Vacuum Gauge W/4-Pin Connector
2
GA14847
GD17151-03
GA9964
1
-
-
Low Pressure Sensor (0-40 IN H
2
0)
Nylon Tubing, ¼" O.D. x 37'
Strain Relief
3
GR1736
1
Hose Barb, ⅛" Barb To ⅛" Male NPT
4
GD15849-02
1
Clear Plastic Tubing, 5∕16" O.D. x 3∕16" I.D. x 120"
5
GA10765
GR1777
1
-
Analog Vacuum Gauge W/Hose Barb
Hose Barb, ⅛" Male NPT To 3∕16" Barb
6
GA10799
1
Breather, ⅛" Male NPT
7
G10001
G10108
1
1
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Nut, ⅜"-16
8
G11215
3
Hex Socket Head Cap Screw, No. 6-32 x ⅜", Grade 8
9
GD15804
1
Mount
10
GD15803
1
Support
11
GA11158
1
Harness, 468"
12
GA11699
-
Extension Harness, 180"
13
GA17547
-
Power Adapter Cable
14
GA11155
GD14258
GD14660
G1K268
1
-
-
-
Harness W/Fuse Holder And Fuse, 132"
Fuse Holder
Fuse, 2 Amp Delay Action
Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp, (1)
Lock Ring, (3) Female Terminal Pins
15
GA8328
-
4-Pin Female Connector Kit, 4 Seals And 4 Pin Contacts
16
GA8329
-
4-Pin Connector W/Male Housing, 4 Seals And 4 Socket Contacts
17
G11166
6
Whiz Lock Bolt, ¼"-20 x ¾"
18
GD16233
1
Manifold
19
GD16241
1
Gasket
20
G11124
7
Whiz Lock Bolt, ⅜"-16 x 1"
21
GA11086
1
Cover
22
G10063
G11387
G10108
2
2
2
Hex Head Cap Screw, ⅜"-16 x 4"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
23
GD15863
1
Discharge Deflector
24
GA11987
2
Screen
25
GD15790
1
Hub
26
GA10635
1
Impeller
27
GD15789
1
Backing Plate
28
G11133
6
Hex Socket Head Cap Screw, 5∕16"-18 x ¾", Grade 8
29
G10599
G10229
G10101
2
2
2
Carriage Bolt, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
30
---
-
See “Vacuum Fan Hydraulic Motor Assembly” on page P57
31
GA11085
1
Shroud
32
---
-
See “Vacuum Fan Motor Valve Block Assembly (Located Below Vacuum Fan Motor
Assembly)” on page P59
33
G11391
G10499
1
1
Flat Washer, ⅝" SAE
Hex Jam Nut, ⅝"-18, Grade 2
34
GA12812
-
Hall Effect Adapter
A
GA11087
-
Vacuum Fan Assembly (Items 17-22 and 24-33 on this page and Items 2, 3 and 8 on
)
Digital Vacuum Gauge, Analog Vacuum Gauge, and Vacuum
Fan Assembly
Model 3500
M0240-02
Rev. 5/13
P54
TM
