P138 – Kinze 3500 Lift and Rotate Planter Rev. 5/14 User Manual
Page 141
ITEM
PART NO.
QTY.
DESCRIPTION
1
GR1425
1
Repair Kit, Includes Item 3
2
GR1144
2
Discharge Valve
3
GR1423
1
Outboard Cylinder
4
GR1142
2
Suction Valve
5
GR1422
1
Inboard Cylinder
6
GR1134
1
Stuffing Box Insert
7
GR1133
1
Retaining Ring
8
GR1130
2
Packing Spring
9
GR1129
3
Washer
10
GR1451
1
Suction Manifold
Liquid Fertilizer Piston Pump (Cylinder Assembly) Uses 18
Tooth Sprocket
Model 3500
M0240-02
6/11
P138
TM
