Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 103)

Planter Hydraulic System
ITEM PART NO. QTY. DESCRIPTION
1 GD4086 4 ISO Coupler
2 *A15008 2 Hose Assembly, ⅜" x 114"
3 G6400-08-06
GR1045 4
-
Connector W/O-Ring, ¾"-16 Male JIC To 9∕16"-18 O-Ring
O-Ring
4 --- - See “Selector Valve” on page P96
5 G6400-06
GR1045 4
-
Connector W/O-Ring, 9∕16"-18 Male JIC To O-Ring
O-Ring
6 *A1153
*A1194 1
-
Hose Assembly, ¼" x 56", 6 Row 30"
Hose Assembly, ¼" x 30", 8 Row 30"
7 *A1141
*A1195 1
-
Hose Assembly, ¼" x 62", 6 Row 30"
Hose Assembly, ¼" x 34", 8 Row 30"
8 *A1109 2 Hose Assembly, ¼" x 145"
9 G6801-06-08
GR1037 4
-
Elbow W/O-Ring, 90°, 9∕16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
10 --- - See “Transport Latch Cylinder, All Sizes” on page P93
11 --- - See “Rotation Cylinder” on page P93
12 *A15007 2 Hose Assembly, ⅜" x 272"
13 *A1026 2 Hose Assembly, ⅜" x 152"
14 G2700-08 4 Bulkhead Tube Union, ¾"-16 Male JIC
15 G306-08 4 Lock Nut, ¾"-16
16 *A1021 4 Hose Assembly, ⅜" x 56"
17 --- - See “Frame Assembly” on page P71
18 G6400-08
GR1037 8
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
19 *A1002 2 Hose Assembly, ⅜" x 20"
20 G6500-08-06 6 Swivel Elbow, 90°, ¾"-16 Male JIC To 9∕16"-18 Female
21 --- - See “Row Marker Sequencing/Flow Control Valve” on page P97
22 G6400-L-06
GR1045 2
-
Long Connector W/O-Ring, 9∕16"-18 Male JIC To O-Ring
O-Ring
23 *A3115
*A1078 2
-
Hose Assembly, ⅜" x 146", 6 Row 30"
Hose Assembly, ⅜" x 174", 8 Row 30"
24 G6801-08
GR1037 6
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
25 --- - See “Row Marker Cylinder” on page P95
26 *A1041
*A1090 2
-
Hose Assembly, ⅜" x 130", 6 Row 30"
Hose Assembly, ⅜" x 162", 8 Row 30"
27 *A1076 1 Hose Assembly, ⅜" x 30"
28 --- - See “Stroke Limiter Valve” on page P96 and See “Frame Assembly” on page P71
29 G6500-08 1 Swivel Elbow, 90°, ¾"-16 Male JIC To Female
30 *A1055 3 Hose Assembly, ⅜" x 66"
31 *A1018 1 Hose Assembly, ⅜" x 40"
32 --- - See “Lift Cylinder” on page P94
33 G6400-08
GR1037
G6400-08-04
GR1465 2
-
2
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To 7∕16"-20 O-Ring
O-Ring
34 G6502-08 4 Swivel Elbow, 45°, ¾"-16 Male JIC To Female
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis.
Call for quote.
Model 3500 M0240-02
6/11 P100
