ITEM PART NO. QTY. DESCRIPTION
1 GR0216 2 Spring Anchor Bar
2 GR0214 4 Spring
3 G10130
G11386
G10144 4
4
4 Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flat Washer, 5∕16" SAE
Wing Nut, 5∕16"-18
4 GR0212 1 Plate
5 GR0207 2 Nylon Bushing
6 G10303
G11386
G10144 2
2
2 Carriage Bolt, 5∕16"-18 x 1"
Flat Washer, 5∕16" SAE
Wing Nut, 5∕16"-18
7 GR0215 6 Metering Hose, ½" x 13"
8 G10681 - Hose Clamp, No. 6
9 G10004
G10101 4
4 Hex Head Cap Screw, ⅜"-16 x 1¼"
Hex Nut, ⅜"-16
10 GR0213 2 Angle
11 GR0217 2 Manifold Plug
12 GR0232 6 Adapter
13 GR0228 1 Intake Manifold
14 GR1484 1 Discharge Manifold Less Hose Barbs
15 G4301-02 1 Hose, ⅜" x 50'
16 GR0211 - Rubber Cap
17 GR0229 6 Nylon Washer
18 GR1626 6 Bushing
19 G10131 2 Square Head Set Screw, 5∕16"-18 x ¾"
20 G10640 8 Grease Fitting, ¼"-28
21 GR0231 2 Roller Arm
22 GR0233 3 Roller
23 G10718 2 Spring Pin, 5∕16" x 1⅛"
24 GD9109 2 Sleeve
25 GD9107 1 Shaft
26 GR0226 2 Shim, 3∕64"
27 GR0225 2 Shim, 1∕32"
28 GR0208 1 Frame
29 GR1577 6 Nylon Hose Barb, ½" x ⅜" (If Applicable)
A GA8691 - Squeeze Pump Complete, 6 Rows (Items 1-13, 15-22 And 25-29)
Liquid Fertilizer Piston Squeeze Pump, 6 Row
Model 3500 M0240-02
6/11 P146
