Contact Wheel and Arm Assembly
ITEM PART NO. QTY.
(Per Wheel)
DESCRIPTION
13 A7369 1 Wheel Arm (Non-Stock Item)(Sub G1K253)
14 G10306
G11387
G10108 1
-
1
Carriage Bolt, ⅜"-16 x 2"
Flat Washer, ⅜" SAE (As Required)
Lock Nut, ⅜"-16
15 G10004
G10229
G10101 2
2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
16 G10751
G10235
G11391
G10412 2
6
2
2 Hex Head Cap Screw, ⅝"-18 x 1¾"
Machine Bushing, ⅞", 14 Gauge
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-18
17 GA2068 2 Spring W/Plug
18 G10501 2 Hex Jam Nut, ½"-13, Grade 2
19 G3310-116
G3310-124
GR0912
1
1
-
Chain, No. 40, 116 Pitch Including Connector Link (Used With 15 And 19 Tooth
Sprockets)
Chain, No. 40, 124 Pitch Including Connector Link (Used With 30 Tooth Sprocket)
Connector Link, No. 40
20 GA5105
GA5107
GA5114 1
-
-
Sprocket, 15 Tooth
Sprocket, 19 Tooth
Sprocket, 30 Tooth
21 G10602 1 Spring Pin, ¼" x 1½"
22 GD6825-10.375 1 Hex Shaft, ⅞" x 10 ⅜" (2 Holes)
23 G10233 6 Machine Bushing, 1½" x 1∕32", 10 Gauge
24 GA9846 - Flanged Bearing, ⅞" Hex Bore
25 G10890 2 Hex Head Adjusting Bolt, ½"-13 x 4", Grade 2
26 GA5090
GD5753
GD5752 -
1
1
Tire And Rim Assembly (Specify Brand*)
Tire, 4.10" x 6" (Specify Brand*)
Inner Tube
27 GD2558 1 Lynch Pin, ¼"
28 G10303
G10232
G10106 -
-
6
Carriage Bolt, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
A G1K253 - Contact Wheel Arm Replacement Kit (Items 13, 18, 21, 22, 24, 25, 27 And 28)
*Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied. Different brand tires may have different diameters. Change
in tire brand may affect rates. Field checks are recommended after any change in contact tires.
