Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 125)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 --- - See “Notched Single Disc Fertilizer Opener” on page P117
2 GD12684 1 Bushing, 1⅓" Long
3 GD11178 1 Adjustment Lever
4 G10603 2 Spring Pin, ¼" x 1¼"
5 G11034
G10111 1
1 Hex Head Cap Screw, ½"-13 x 7"
Lock Nut, ½"-13
6 G10830
G11391
G10107 1
1
1 Hex Head Cap Screw, ⅝"-11 x 7½"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
7 GD11836 1 Sleeve, 2⅛" Long
8 GD7962 1 Spring
9 G10306
G11387
G10108 1
1
1 Carriage Bolt, ⅜"-16 x 2"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
10 GA7999
GA7998
G10640 1
-
-
Mount W/Grease Fitting, L.H. (Shown)
Mount W/Grease Fitting, R.H.
Grease Fitting, ¼"-28
11 G10133
G10109 6
6 Hex Head Cap Screw, 5∕16"-18 x 1½"
Lock Nut, 5∕16"-18, Grade 8
12 GD1132 2 Dust Cap
13 GD10552 2 Wheel, 12 Tine, ⅜" x 12"
14 GA5654
GA2014 1
-
Hub W/Bearings
Bearing
15 GD9724 1 Backing Plate
16 GD7817-04 1 Spacer, 11∕16" I.D. x ½" Long
17 GD11188 1 Spacer
18 G10908
G10503 1
1 Carriage Bolt, ⅝"-11 x 3"
Hex Jam Nut, ⅝"-11, Grade 2
19 GD11265
GD11266 1
-
Spring, L.H. (Shown)
Spring, R.H.
A GA7445
GA7446 -
- Wheel Assembly, 12 Tine, L.H. (Items 11 And 13-15)(Shown)
Wheel Assembly, 12 Tine, R.H. (Items 11 And 13-15)
Residue Wheel Attachment for Notched Single Disc Fertilizer
Opener
Model 3500 M0240-02
6/11 P122
