Axle/Pivot and Wheel Assembly
ITEM PART NO. QTY. DESCRIPTION
1 GA6849 1 Safety Lockup Pin
2 G10606
G10671
1
1
Spring Pin, ¼" x 2"
Slotted Spring Pin, 3∕16" x 3¼"
3 G10716 1 Hex Head Cap Screw, ¾"-10 x 1"
4 GA7543 1 Center Post
5 GA6496
GD9121
1
-
Bearing Housing W/Cups, Less Grease Fitting
Cup
6 GA6435 2 Bearing
7 GD9130 1 O-Ring
8 GD9051 1 Bearing Cap
9 G10230 3 Lock Washer, ⅝"
10 G10006 3 Hex Head Cap Screw, ⅝"-11 x 2¼"
11 GD9124
GD9123
GD9122
4
4
4
Shim, .020" Thick (As Required)
Shim, .007" Thick (As Required)
Shim, .005" Thick (As Required)
12 G10779 1 Grease Fitting, 90°, ¼ "-28
13 G10028
G10105
8
8
Hex Head Cap Screw, ¾"-10 x 3"
Hex Nut, ¾"-10
14 GD2169 8 Special Washer, 25∕32" I.D. x 1¼" O.D., Hardened
15 GA8911 1 See “Rotation Cylinder” on page P93
16 GR0193 4 Hair Pin Clip
17 GR0375 2 Pin, 1" x 3½"
18 G10231 8 Lock Washer, ¾"
19 G10026 12 Hex Head Cap Screw, ¾"-10 x 2"
20 G11314 4 Serrated Flange Nut, ¾"-10
21 GA14416
G10636
G10071
GD20458
GD20456
4
2
2
1
1
Mud Scraper Assembly
Carriage Bolt, ½"-13 x 1½"
Serrated Flange Nut, ½"-13
Slotted Scrapper
Short Scraper Arm
22 GR0270 24 Lug Bolt, 9∕16"-18
23 GD13401 1 Tire, 7.50" x 20", 8 Ply, Tubeless W/O Center Rib (Specify Brand*)
24 GA7434 1 Valve Stem
25 GA14413 1 Rim, 5.50" x 20"
26 GA2148
GR0434
1
-
Hub W/Cups, 6 Bolt
Cup
27 GA0895 2 Bearing
28 GA4693
GD11490
1
-
Spindle, W/Round External Retaining Ring, 10½"
Round External Retaining Ring
29 G11081 2 Hex Jam Nut, 1½"-12, Grade 2
30 GA17063
GA17067
GA17066
1
-
-
Axle W/Stub (Domestic)
Axle W/Stub (Export)
Stub Axle
31 G10027 6 Hex Head Cap Screw, ¾"-10 x 2½"
32 G10231 6 Lock Washer, ¾"
33 G10105 6 Hex Nut, ¾"-10
34 GA6529 - Rock Guard (Optional)
35 G10037
G10228
G10102
-
-
-
Hex Head Cap Screw, ½"-13 x 1¼"
Lock Washer, ½"
Hex Nut, ½"-13
A GA14412 4 Tire and Rim Assembly (Specify Brand*) (Items 23-25)
B GA6428 4 Hub And Spindle Assembly (Items 26-29)
*Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied. Different brand tires may have different diameters. Change
in tire brand may affect rates. Field checks are recommended after any change in contact tires.
Model 3500 M0240-02
Rev. 7/12 P76
