Kinze 3500 Lift and Rotate Planter Rev. 5/14 User Manual
Page 69
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA8699
1
Inner Hitch, 65¼"
2
G10169
G10157
1
1
Hex Head Cap Screw, 1¼"-7 x 6"
Lock Nut, 1¼"-7
3
GD16328
1
Hose Holder
4
G10217
G10230
G10104
2
1
1
Washer, ⅝" USS
Lock Washer, ⅝"
Hex Nut, ⅝"-11
5
GA13986
GA4995
GR0516
GR0515
1
-
-
-
Jack Assembly Complete
Detent Pin Assembly
Crank Assembly
Bevel Gear Set, Includes: (2) Bevel Gears, (1) Gear Pin, (1) Groove Pin
6
GB0156
1
Clevis
7
---
-
8
GA13595
G1K411
1
-
Safety Chain W/Hook, ⅜"
Safety Chain Repair Kit, Includes: Hook, Flat Washer, Latch Pin, Safety Latch,
Spring And Retaining Ring
9
G10494
GD10646
G10157
1
1
1
Hex Head Cap Screw, 1¼"-7 x 3½"
Special Washer
Lock Nut, 1¼"-7
10
GA10709
1
Inner Hitch, 65¼", 7½" Offset
Inner Hitch/Safety Chain
Model 3500
M0240-02
6/11
P66
TM
