Kinze 3500 Lift and Rotate Planter Rev. 5/14 - Manual (Page 112)

KPM III Electronic Seed Monitor
ITEM PART NO. QTY. DESCRIPTION
30 G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
31 G1K252
G1K363
-
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
32 GD11089 - Sealing Plug
33 GD18168 2 Mount
34 GD18118 2 Shaft Sensor Mount
35 G10686
G10229
G10101 4
4
4 Hex Head Cap Screw, 3/8”-16 x 8”
Lock Washer, 3/8”
Hex Nut, 3/8”-16
36 GR1415 1 Rotation Sensor
37 G11288
G10243
G10758 2
2
2 Pan Head Screw, No. 10-32 x 1 ¼”
Washer, No. 10 SAE
Hex Nut, No. 10-32
38 GD11474 2 Cover
39 G10927
G10931
G10928 2
2
2 Pan Head Machine Screw, No. 8-32 x 1 1/4”, Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
40 GR1414 1 Actuator
A GA6147 - Magnetic Distance Sensor And Mounting Package (Items 4-9)
B GR1763 - KPM III Loaner (Display Only)
C GA13521 - Shaft Sensor Mounting Package (Items 33-35 and 37-39)
D GA8135 - Shaft Rotation Kit, Includes: (2) Actuators (2) Rotation Sensors
TM
M0240-02 Model 3500
P109 Rev. 5/13
