12 Transducer Blocks
ID Name Structure Data type Bytes Access Store See section
101 Block Type
ID
Simple OSTRING(n) 4 1_R
2_R
N 12.1.1
102 Status
Extension
Simple UINT8 1 1_R
2_R
V 12.1.2
103 Sensor
Alarm
Array UINT8 2 1_R
2_R
V 12.1.3
104 Sensor
Warning
Array UINT8 2 1_R
2_R
V 12.1.4
105 Sensor
Temperature
Simple FLOAT 4 1_R
2_R
NV 12.1.5
201 Offset Simple *) - 1_R/W
2_R/W NV 12.1.6
202 Filter Simple UINT8 1 1_R/W
2_R/W NV 12.1.7
*) According to data type value (ID 21)
The Block Type ID Parameter contains an ID which describes the block type. The
block type ID of the "CDG Transducer Block" is set to "14". The other defined block
types are listed in Appendix B.
This bit mapped byte parameter provides the following additional information of the
CDG sensor (Instance 1):
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Res. Res. Res. Res. Res. Underrange
Exceeded
Overrange
Exceeded
Reading
Invalid
Res. = Reserved
• Underrange
Exceeded
This bit is set ("1") if the ProcessValue PV is below the parameter Underrange
(ID 45) of the CDG sensor instance. See section 8.1.21.
• Overrange Exceeded
This bit is set ("1") if the ProcessValue PV is above the parameter Overrange
(ID 44) of the CDG sensor instance. See section 8.1.20.
• Reading invalid
This bit represents the logical inversion of the parameter "Reading Valid"
(ID 23) of the CDG sensor instance. See section 8.1.8.
This parameter contains the following information:
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Byte 0 0 0 0 0 0 0 0 DF
Byte 1 0 0 0 0 0 OT EF 0
• DF = Diaphragm Failure
This bit is always set to "0".
• OT = Over Temperature of Electronics
This bit is set to "1" if an Electronics Overtemperature error occurs.
• EF = Electronics Failure
This bit is set to "1" if a Temperature Sensor error occurs.
12.1 CDG Transducer Block
(Instance 1)
12.1.1 Block Type ID (ID 101)
12.1.2 StatusExtension
(ID 102)
12.1.3 Sensor Alarm (ID 103)
