There are a number of special commands for bringing the gauge into a status it
does not automatically go to.
ID Name Structure Data type Bytes Access Store Range
15 Device Block
State
Command
Simple UINT8 1 1_R/W
2_R/W
N → below
The device block state method allows the master to force the behavior of the
device block state machine (as shown in parameter device state) by setting it to
one of the values shown in the table below. Depending of the actual state, some
values may not be allowed at a time.
ID value Name Description
0 Inactive No action.
1 Reset Used for reinitializing the device.
2 Abort Brings the device to the ABORT status.
3 Recover Used for bringing the device from the ABORT
status into the Recovered State ≙ IDLE.
4 Execute Brings the unit to the EXECUTING status, in which
the gauge functions normally. As soon as cyclic
data traffic is initialized, this status command is
executed automatically.
5 Stop Brings the gauge to the IDLE status.
6 Perform
Diagnostic
Stops the running activity and starts SELFTEST.
7…127 Reserved by
PNO
128…255 Manufacturer
specific
7.2.2 Device Block State
Command (ID 15)
