This parameter contains the valid maximum measurement scale of the device in
terms of the currently selected data type (ID 21) and data unit (ID 22).
Sensor Type COUNTS Torr mbar Pascal
1000 Torr 32767 1024 1365 136500
500 Torr 32767 512 682.6 68260
200 Torr 32767 204.8 273.0 27300
100 Torr 32767 102.4 136.5 13650
50 Torr 32767 51.2 68.26 6826
20 Torr 32767 20.48 27.30 2730
10 Torr 32767 10.24 13.65 1365
5 Torr 32767 5.12 6.826 682.6
2 Torr 32767 2.048 2.730 273.0
1 Torr 32767 1.024 1.365 136.5
500 mTorr 32767 0.512 0.6826 68.26
200 mTorr 32767 0.256 0.2730 27.30
100 mTorr 32767 0.1024 0.1365 13.65
1000 mbar 24576 768.063 1024 102400
500 mbar 24576 384.031 512 51200
200 mbar 24576 153.613 204.8 20480
100 mbar 24576 76.8063 102.4 10240
50 mbar 24576 38.4031 51.2 5120
20 mbar 24576 15.3613 20.48 2048
10 mbar 24576 7.68063 10.24 1024
5 mbar 24576 3.84031 5.12 512
2 mbar 24576 1.53613 2.048 204.8
1 mbar 24576 0.768063 1.024 102.4
0.5 mbar 24576 0.384031 0.512 51.2
0.2 mbar 24576 0.153613 0.256 25.6
0.1 mbar 24576 0.0768063 0.1024 10.24
When the gauge is not in the EXECUTING status (ID 25, Device Block) or if there
is a device error, a value defined by Safe State is output as pressure value. You
can select among the following Safe State values:
Option Coding ProcessValue (PV) behavior
Zero 0 The PV is set to 0.
Full Scale 1 The PV is set to the full scale value (ID 24).
Hold Last Value 2 The PV is set to the last valid value obtained in
the EXECUTING status.
Use Safe Value 3 The PV is set to the Safe Value (ID 40).
8.2.7 Full Scale (ID 24)
8.2.8 Safe State (ID 39)
